18V MultiVolt™ Cordless 10 Inch Single Bevel Miter Saw Kit | Metabo HPT C1810DFA

Model# C1810DFA

  • CORDLESS PORTABILITY: Freedom to GO work anywhere
  • KIT INCLUDES: 18V/36V high capacity 5.0 Ah MultiVolt Battery to GO longer
  • CUTS PER CHARGE: 180 2 x 4 cuts on a single charge
  • Xact CUT LED SHADOW SYSTEM: To clearly mark the cut line and works in any lighting condition for ultimate accuracy

Features

CORDLESS PORTABILITY

Freedom to GO work anywhere

Xact CUT LED SHADOW SYSTEM

To clearly mark the cut line and works in any lighting condition for ultimate accuracy

BRUSHLESS

Technology for high efficiency, increased runtime and longer tool life

CUTS PER CHARGE

180 2 x 4 cuts on a single charge

The C1810DFA is a 18V MultiVolt Cordless 10 Inch Single Bevel Miter Saw Kit - the first of its kind in the market. In addition to the Xact Cut LED Shadow Line system for cutting accuracy, this miter has a sweeping 52 degree miter capacity to the left and right and a 45 degree left bevel capacity to make compound cuts in any lighting condition with ease. This cordless miter saw weighs in at just 19.6 lbs. for a perfect combination of sturdiness and portability for the professional or DIYer looking for a time-saving miter saw at a great price. The kit comes with a 18V/36V 5.0 Ah MultiVolt battery and a rapid charger with USB port that can power through 180 2 x 4 cuts on a single charge. Additional features include multiple common miter stops, electric brake, a thumb activated miter lock, a super efficient brushless motor capable of 3,800 RPM, a large extendable rip fence to help cut large work pieces, and 5-year Metabo HPT warranty for peace of mind.

This 18V MultiVolt Cordless 10" Single Bevel Miter Saw is part of the expanding MultiVolt System of 18-Volt and 36-Volt power tools from Metabo HPT. GO lighter with 18V batteries or GO longer with the unique MultiVolt battery that works on both 18V and 36V tools to double your runtime for up to 8.0Ah* of runtime per charge for more power on the GO.


Features of the 18V Cordless 10 Inch Single Bevel Miter Saw

  • CORDLESS PORTABILITY: Freedom to GO work anywhere
  • KIT INCLUDES: 18V/36V high capacity 5.0 Ah MultiVolt Battery to GO longer
  • COMPOUND CUTTING: Wide range of miter and bevel cutting options
  • Xact CUT LED SHADOW SYSTEM: To clearly mark the cut line and works in any lighting condition for ultimate accuracy
  • CUTS PER CHARGE: 180 2 x 4 cuts on a single charge
  • CAPACITY: Up to 5-21/32" at 90 degrees
  • CUTTING SPEED: 3,800 RPM max no-load speed
  • BRUSHLESS: Technology for higher efficiency, increased runtime and longer tool life
  • ELECTRIC BRAKE: Stops blade rotation within seconds to prevent unintentional cuts
  • STABILITY: Extendable rip fence and a large table
  • SIZE: Extra large base for great support and handling of material
  • LED LIGHT: Convenient for use in dark spaces
  • BEVEL RANGE: 0 - 45 degrees to the left
  • MITER RANGE: 0 - 52 degrees to left and right
  • ERGONOMICS: Classic Metabo HPT controls and comfort while cutting
  • LIGHTWEIGHT: 19.6 lbs. for ease of transport
  • 5 - YEAR WARRANTY: Tool Body only
  • ALSO AVAILABLE: Tool Body Only C1810DFAQ4
  • TOOL CARD: Download the C1810DFA Tool Card

Included with the 18V Cordless 10 Inch Single Bevel Miter Saw
  • Battery (BSL36A18)
  • Battery Charger (UC18YSL3)
  • 10 in. (255mm) TCT Saw Blade for Wood (No. of teeth 24) (318963)
  • Dust Bag (322955M)
  • 5 mm Hex. Bar wrench (944459)
  • Vise Assembly w/knob bolt
  • Holder
  • Side Handle
  • Sub Fence
  • Flat Screw
  • M6 Nylon Nut
  • Plate (A)
Optional Accessories for the 18V Cordless 10 Inch Single Bevel Miter Saw
  • Battery (BSL36B18
  • Battery Charger (UC18YSL3)
  • Holder (974562M)
  • 6 mm machine screw (949258)
  • Extension Holder and Stopper (322710)
  • Saw Blade 10 in (255 mm) TCT Saw blade for Wood Cut (Total Teeth 60) (976472)
  • Saw Blade 10 in. (255 mm) TCT Saw blade for Aluminum Cut (Total Teeth 100) (319658)
  • Crown Molding Vise Ass'y (322712)
  • Crown Molding Stopper (L) (322713)
  • Crown Molding Stopper (R) (322714)

Specifications


Voltage 18V
Battery Type Lithium Ion Slide-Type
Motor DC Brushless
Blade Diameter10 in.
Arbor5/8in
No-Load Speed3,800 Power Mode (RPM)
Miter RangeLeft & Right 0°-52°
Miter Detent StopsRight/Left;
Bevel RangeLeft 0°-45°
Bevel StopsAdjustable 0°-45°
Cut Capacity at 90°2-5/16 in. (59 mm) x 5-31/32 in. (144 mm)
Miter Left 45°2-5/16 in. (59mm) x 4 in. (102 mm)
Bevel Left 45°1-5/8 in. (41 mm) x 5-21/32 in. (144 mm)
Miter & Bevel Left 45°1-5/8 in. (41mm) x 4 in. (102 mm)
Height 21.5"
Weight19.6 lbs
LED Light Yes
Xact Cut LED Shadow LineYes
Constant Speed ControlYes
Positive StopsL/R 0, 15, 22.5, 31.6, 45 degrees
Warranty5-Year Tool Body
Battery Warranty2-Year
Charger Warranty1-Year

Includes


Included with the 18V Cordless 10 Inch Single Bevel Miter Saw

  • Battery (BSL36A18)
  • Battery Charger (UC18YSL3)
  • 10 in. (255mm) TCT Saw Blade for Wood (No. of teeth 24) (318963)
  • Dust Bag (322955M)
  • 5 mm Hex. Bar wrench (944459)
  • Vise Assembly w/knob bolt
  • Holder
  • Side Handle
  • Sub Fence
  • Flat Screw
  • M6 Nylon Nut
  • Plate (A)

Optional Accessories for the 18V Cordless 10 Inch Single Bevel Miter Saw

  • Battery (BSL36B18)
  • Battery Charger (UC18YSL3)
  • Holder (974562M)
  • 6 mm machine screw (949258)
  • Extension Holder and Stopper (322710)
  • Saw Blade 10 in (255 mm) TCT Saw blade for Wood Cut (Total Teeth 60) (976472)
  • Saw Blade 10 in. (255 mm) TCT Saw blade for Aluminum Cut (Total Teeth 100) (319658)
  • Crown Molding Vise Ass'y (322712)
  • Crown Molding Stopper (L) (322713)
  • Crown Molding Stopper (R) (322714)
