21 Degree Plastic Collated 3-1/2 Inch Framing Nailer | Metabo HPT NR90AES1
Model# NR90AE(S1)
- AWARD: Rated the Pro Preferred Nailer for 9 years running (2014 - 2022) by Builder and Developer Magazine
- SELECTIVE ACTUATION: Allows for quick changes between sequential and contact nailing with the flip of a switch
- LIGHTWEIGHT: At only 7.5 lbs and well-balanced allowing for ease of maneuverability and less user fatigue
- WARRANTY: Covered by Metabo HPT's Professional 5-Year Tool Warranty
- AWARD: Rated the Pro Preferred Nailer for 9 years running (2014 - 2022) by Builder and Developer Magazine
- SELECTIVE ACTUATION: Allows for quick changes between sequential and contact nailing with the flip of a switch
- LIGHTWEIGHT: At only 7.5 lbs and well-balanced allowing for ease of maneuverability and less user fatigue
- WARRANTY: Covered by Metabo HPT's Professional 5-Year Tool Warranty
Features
EASY SWITCH BETWEEN SINGLE TO BUMP FIRE
Quickly switch between sequential and bump nailing with the simple flip of a switch
APPLICATIONS
For framing, flooring, roof decking, window build-up, and more
PRO PREFERRED NAILERS
Product Brand Surveys in Builder & Developer Magazine for 9 years running (2014 - 2022)
WARRANTY
Covered by Metabo HPT's professional 5-year Warranty
This 21 Degree Plastic Collated Framing Nailer (NR90AES1) drives plastic collated nails from 2" up to 3-1/2" in length and features Metabo HPT's next generation "industrial design." Weighing only 7.5 lbs, it is easy to use all day, while still providing the power as other bulkier and heavier framing nailers. This nailer easily switches from bump fire to contact nailing with a simple flip of a switch. Plus, with the tool-less depth adjustment, adjusting the nail depth to the material is quick and easy.
The Framing nailer is ideal for flooring and framing, truss build-up, window build-up, sub flooring, roof decking, wall sheathing and housing construction.
The Framing nailer is ideal for flooring and framing, truss build-up, window build-up, sub flooring, roof decking, wall sheathing and housing construction.
Features of the 3-1/2" Plastic Collated Framing Nailer Metabo HPT
- AWARD: Rated the Pro Preferred Nailer for 9 years running (2014 - 2022) by Builder and Developer Magazine
- APPLICATIONS: Great Framing nailer for flooring and framing, truss build-up, window build-up, sub flooring, roof decking, wall sheathing and housing construction
- LIGHTWEIGHT: At only 7.5 lbs and well-balanced allowing for ease of maneuverability and less user fatigue
- SELECTIVE ACTUATION: Allows for quick changes between sequential and contact nailing with the flip of a switch
- TOOL-LESS DEPTH ADJUSTMENT: Depth adjustment to countersink or flush drive into a variety of materials
- FASTENERS: Accepts 2-in up to 3-1/2-in plastic collated framing nails
- NEW HEAD GUARD DESIGN: Allows for quicker disassembly during tool maintenance
- RECOMMENDED: Use Metabo HPT Nails for best results
- WARRANTY: Covered by Metabo HPT's Professional 5-Year Tool Warranty
- COMPLIANT: Safety standards for pneumatic nailers in the United States
- TOOL CARD: Download the NR90AE(S1) Tool Card
Warranty for the Framing Nailer:
- Covered by Metabo HPT's professional 5-year Warranty
Included with Framing Nailer:
- NR90AE(S1) framing nailer
- Safety Glasses (875769)
Specifications
| Fastener Type | Plastic Collated framing nails |
| Magazine Angle | 21 Degree |
| Fastener Length Capacity | 2" - 3-1/2" |
| Fastener Diameter Range | .113 - .148 |
| Magazine Capacity (.131) | 64 Nails |
| Magazine Loading | Rear |
| Operating Pressure | 70-120 PSI |
| Air Consumption @ 100 PSI | .09 scfm |
| Depth Adjustment | Tool-less |
| Actuation | Selective |
| Jam Clearing | Open Nose |
| Dry-Fire Lockout | No |
| Adjustable Exhaust Port | No |
| Rubber Grip | Yes |
| LxWxH | 20-3/4" x 4-15/16" x 12-11/16" |
| Weight | 7.5 lbs |
| Warranty | 5-Year |
Includes
- NR90AES1 framing nailer
- Safety Glasses (875769)
