5" 12 Amps TE 13-125 Diamond Cutting System (Concrete) | Metabo HPT 646431420

Model# 646431420

  • Compact diamond cutter for low-dust dry cuts up to 1-1/16" (27 mm) in mineral-based materials
  • Efficient dust extraction for health protection and cleaner construction sites
  • Metabo HPT Long-life motor with patented dust protection for long service life
  • Suitable for universal use with pushing cuts and plunge function

  • Compact diamond cutter for low-dust dry cuts up to 1-1/16" (27 mm) in mineral-based materials
  • Efficient dust extraction for health protection and cleaner construction sites
  • Metabo HPT Long-life motor with patented dust protection for long service life
  • Suitable for universal use with pushing cuts and plunge function

Features

The Metabo HPT TE 13-125, 4.5"/5" Pro series Angle Grinder is German engineered and manufactured for extreme durability, safety, and productivity in a broad range of industrial grinding, cutting, beveling, deburring, brushing, and finishing applications. The powerful LongLife 12.0 Amp. AC/DC. 9,600 RPM motor delivers up to 50% more torque for faster material removal and up to 20% higher overload capacity for ultimate durability. For cooler operation and extended longevity in demanding working environments the patented motor includes: unobstructed rear air intake, optimized internal air flow, and epoxy coated copper windings that extend outside of the field coil for advanced heat dissipation and protection from abrasion, In addition, the winding protection grid extends the life of the armature up to 5 times in harsh environments, and the full die-cast bearing flange and oversized bearings offer extend service life. The grinder's safety is enhanced by the patented Metabo HPT S-Automatic mechanical safety slip clutch which reduces the likelihood of kickback by helping the user maintain control if the accessory jams. The ergonomic grip design reduces fatigue and includes a Lock-on slide switch that provides comfort for extended grinding applications. The Metabo HPT MVT Anti-Vibration Side Handle is designed with a blub-shaped grip and 15-degree offset to reduce vibrations by up to 60% providing optimal handling, reduced fatigue, and excellent ergonomics by distributing forces evenly across the hand, lowering the risk of long term work-related disorders of the hand, wrist and arm. The tool features a tool-free adjustable guard for convenient positioning and safety when grinding and cutting. The die-cast aluminum gear housing is designed to dissipate heat from the motor, features oversized bearings and heavy-duty gearing, and is rotatable to allow for multiple switch positions.

Features of the 5" 12 Amps TE 13-125 Diamond Cutting System (Concrete)

  • Compact diamond cutter for low-dust dry cuts up to 1-1/16" (27 mm) in mineral-based materials
  • Efficient dust extraction for health protection and cleaner construction sites
  • Metabo HPT Long-life motor with patented dust protection for long service life
  • Suitable for universal use with pushing cuts and plunge function
  • Precise cuts in even surfaces thanks to metal base plate with rollers, removable for free-handed cutting
  • Usable with guide rails for long, straight cuts
  • Safety and control in every situation: S-automatic safety clutch and restart protection
  • Extraction hood can be mounted tool-free, made of anti-static plastic
  • Auto-stop carbon brushes to protect the motor
  • Connection for dust extraction 1-1/2"
  • 3-year warranty

Standard Accessories

  • (1) 5" 12 Amps TE 13-125 Diamond Cutting System
  • Guard
  • Spanner Wrench
  • Inner Support Flange
  • Nut with two holes
  • Side handle Metabo HPT VibraTech (MVT)

Specifications

Amps12 Amps
Cutting Disc5"
Max. Cutting Depth1 1/6"
Rated Input Power1350 W
Output Power830 W
No-load Speed9600 RPM
Spindle Thread5/8" - 11 UNC
Weight (without power cable)5.5  lbs
Cable Length8 ft



Includes

  • (1) 5" 12 Amps TE 13-125 Diamond Cutting System
  • Guard
  • Spanner Wrench
  • Inner Support Flange
  • Nut with two holes
  • Side handle Metabo HPT VibraTech (MVT)
